KYORITSU – 2500

Harga :

CALL

Merk :

Kyoritsu

Pengiriman :

1 hari sejak pembayaran

Lokasi :

DKI Jakarta - Jakarta Pusat

Dilihat :

106 Kali

Update Terakhir :

08-08-2018 11:44

Dapatkan Spesifikasi Harga KYORITSU – 2500 Produk Terbaik dari PT. ANDALAN BANGUN SEJAHTERA Importir dan Distributor Peralatan Laboratorium dan Alat Uji Ukur

Detail Produk

Product Description

0.01mA resolution for DC current
Top class measurement 0.2% accuracy
Φ6mm clamp jaw easy to use in tight places
Measurement from 0.01mA to 120.0mA
Dual display with backlight shows both mA measurement and percent of 4-20 mA span
Spotlight for illuminating measurement point
Analog output terminal for recorder connection
Complies with IEC 61010-1 CAT II 300V

Specification

DC A

20/100mA (Auto ranging)

	±0.2%rdg±5dgt	(0.00mA – 21.49mA)
	±1.0%rdg±5dgt	(21.0mA – 120.0mA)

Conductor size

Ø6mm max.

Analog output

Recorder: DC 1000mV against DC 100mA

Withstand voltage

2210V AC for 5 seconds

Applicable standards

IEC 61010-1, 61010-2-030 CAT II 300V
IEC 61010-2-032
IEC 61326-1, 61326-2-2
IEC 60529 IP40

Operating temperature & humidity

-10 – +50ºC < 85%

Storage temperature & humidity

-20 – +60ºC < 85%

Power source

R6/LR6 (AA) (1.5V) × 4

Dimensions

111(L) × 61(W) × 40(D)mm : Display unit
104(L) × 34(W) × 20(D)mm : Sensor
700mm : Sensor cable

Weight

Approx. 290g (including batteries)

Accessories

9096 (Carrying case), LR6 (AA) × 4,
Instruction Manual

Optional

(Output cord)
